Description
General Specs
Channels 1
POWER SUPPLY
Power supply voltage / fuse: 11 ÷ 15 VDC / 3 x 30 A
Idling current (power ON/OFF) 0.8 A / 1 mA
Consumption @ 2 Ω, 14.4 VDC (Max Musical Power): 45 A
Remote In: 7 ÷ 15 VDC – 1 mA
ART: Automatic Remote Turn-On/Off with Speaker-In
AMPLIFIER STAGE
Distorsion – THD (100 Hz @ 4 Ω): 0.25%
Bandwidth: 10 ÷ 500 Hz
S/N Ratio (A weighted @ 1 V): 100 dB
Damping factor (100 Hz @ 4 Ω): > 100
Pre-In sensitivity: 0.2 ÷ 5 VRMS
Speaker-In sensitivity: 0.8 ÷ 20 VRMS
Load impedance (MIN)
@ 1 Ch: 2 Ω
Max size (mm / in.): 315 x 190 x 50 / 12.40 x 7.48 x 1.97
Weight (kg / lb.): 3 / 6,61
Adjustable Crossovers yes
Output Power
Output Power (RMS) @ 14.4 VDC, THD 1%
1 Ch: 600 W x 1 (4 Ω)
1 Ch: 1100 W x 1 (2 Ω)
Output Power (RMS) @ 14.4 VDC, THD 10%:
1 Ch: 740 W x 1 (4 Ω)
1 Ch: 1240 W x 1 (2 Ω)
CEA 2006-A Ratings:
RMS Power (4 Ω, ≤1 %THD + N, 14.4 V): 600 W x 1 Ch
S/N Ratio (ref. 1 W output): 80 dBA
Total Power RMS 1240 W
INPUTS / FILTERS
INPUTS: PRE IN / SPEAKER IN
Pre out Hi-Pass: 50 ÷ 250 Hz @ 12 dB/Oct.
Filters FULL: Yes
Lo-Pass: 50 ÷ 250 Hz @ 24 dB/Oct.
SUBSONIC (on/off): 25 Hz @ 24 dB/Oct.
BOOST 50 Hz (adjust): (0 ÷ 6) dB
PHASE(adjust): (0 ÷ 180) deg
Remote Volume Control (adjust): (-50 ÷ 6) dB
