Product Highlights:
Technical Data
Comp Woofer
Size 165 mm (6.5″)
Power Handling 150 W Continuous Power
300 W Peak Power
Impedance 4 Ω
Frequency Response 40 ÷ 4500 Hz
Sensitivity 87 dB/Spl
Magnet N48 “H-grade” Neodymium
Cone TPX®
Brands, Morel, Tempo Ultra MKII, 2-Way Component Systems
6″ x 9″ 2-Way Component Speakers
Peak: 560 watts per pair / 280 watts each | RMS: 300 watts per pair / 150 watts each
Impedance: 4 Ohm | Frequency Response: 50Hz – 22,000Hz | Sensitivity: 92dB | Mounting Depth: 3.35″ (85mm)
High-Grade Ferrite Magnet | Copper Voice Coil Wire | Treated Paper Composite Cone
1.1″ Soft Dome Tweeter | MXR Direct Crossovers
THG 1.5 II
THG 1.5 II optional mesh grilles dedicated to TH 1.5 Violino can be defined with only one word: unique. They are made with finest steel without any compromise, to overcome the absolute.
Comp Tweeter
Size 38 mm (1.5″)
Power Handling 200 (Hi-Pass filtered @ 1,8kHz – 12 dB Oct.) W peak
Impedance 6 Ohm
Frequency Response 800 ÷ 26k Hz
Sensitivity 93 dB/Spl
Magnet N38 “H-grade” Neodymium
Dome Tetolon fibre
